HA05 Premium: Zone 1 Upgrade

HA05 Premium: Zone 1 Upgrade

Zone 1

Built on the HA05 Conquer, the new HA05 Premium is now Zone 1 certified. It keeps the same wattage range and mounting method while being better suited to harsh, high-risk, hazardous environments.

  • Material: Copper-free Aluminum;
  • Lumen Output: 4200LM–33600 LM;
  • Color Options: Warm to Cool White, plus RGB/Amber LEDs available;
  • Clear glass and diffused glass optional;
  • Pendant mount, Ceiling mount, Trunnion mount, Wall mount, 25° Stanchion mount, 90° Stanchion mount;
  • Protection Ratings: IP66 & IK08;
  • Operating Temperature Range: -40°C to 65°C.
HA05 Z1 Congueror Premium 01HA05 Z1 certification and compliance 02HA05 Z1 key features 03HA05 Z1 loop in loop out 04HA05 Z1 beam angle colors 05
IECEx:

Ex eb mb IIC T4 Gb
Ex tb IIIC T90℃ Db IP66

ATEX:

II 2G Ex eb mb IIC T4 Gb
II 2D Ex tb IIIC T90℃ Db IP66

Series Code HA05 Premium
Power 50W, 75W, 100W, 120W, 150W, 200W, 240W
Efficacy 140lm/W
IP Rating IP66
IK Rating IK08
CCT 2000K~6500K:Red/Green/Blue/AmberK
Operating Temperature -40°C to 65°C
Mounting Option Pendant mount, Ceiling mount, Trunnion mount, Wall mount, 25° Stanchion mount, 90° Stanchion mount, Pendant & Trunnion mount
